*This item is not eligible for shipping. Pick-up in store only

Spindle travels a full 5” with one revolution of the handle

Large 14" x 19" precision ground work table features twin T-slot grooves and 4 table slots to accommodate any project

One-handed belt tensioning allows for rapid speed changes

Power switch features a safety key and large, paddle-style off button

Integrated depth stop makes repetitive drilling quick and easy

Style (Type): Floorstanding Model

Swing (In.): 16-7/8

Spindle Travel (In.): 5

Number of Spindle Speeds: 16

Spindle Speed Range (RPM): 210 - 3500

Spindle Distance to Table (Max.) (In.): 30

Table Size (L x W) (In.): 14 x 19

Table Tilt (Deg.): 90 Left and Right

Chuck Distance to Base (In.): 42-7/8

Chuck Distance to Table (In.): 25-7/8

Chuck Size (In.): 5/8

Column Diameter (In.): 3-5/32

Base Size (In.): 20 x 12-5/8

Motor Power (HP): 3/4

Motor Phase (PH): 1

Motor Amps: 6.8

Recommended Circuit Size (Amps.): 15
